GNU/Linux - Comment mettre en place un VPN IPsec multisite entre Racoon et strongSwan

Mise à jour le 18 août 2021

Je vais mettre ici la configuration complète d'un VPN IPsec Multi-site que j'ai du mettre en place.

L'architecture est composée de trois routeurs avec des versions de Debian et solutions IPsec (ipsec-tools et strongSwan).
- Headquarters : Debian 9 avec ipsec-tools et règles nftables
- Branch Office 1 : Debian 8 avec ipsec-tools and règles iptables
- Branch Office 2 : Debian 10 avec strongSwan and règles nftables

Avant de commencer :
- Le projet ipsec-tools (et racoon) est abandonné et ne sera donc plus disponible dans les futures releases Debian. Il peut quand même être interessant de voir comment le faire fonctionner avec strongSwan dans le sens ou il est encore présent dans de nombreuses configurations.
- Nous aurins pu ajouter un tunnel IPsec entre Branch Office 1 et Branch Office 2 mais je ne l'ai pas fait car seule une petite portion de trafic est censée transité entre les deux Branch Office (en fait dans mon cas, que de la VoIP).

Architecture Cible

Site 1 - Headquarters

Configuration

OS : Debian 9
VPN : ipsec-tools
Netfilter tool : nftables

Installation

root@host:~# apt install ipsec-tools racoon nftables

root@host:~# systemctl enable nftables.service

/etc/nftables.conf

#!/usr/sbin/nft -f

flush ruleset

table inet filter {
        chain input {
                type filter hook input priority 0; policy accept;
	}
        chain forward {
                type filter hook forward priority 0; policy accept ;
	}
	chain output {
                type filter hook output priority 0; policy accept;
        }
}

table ip my_nat {
        chain my_masquerade {
                type nat hook postrouting priority 100;
                ip daddr != { 10.0.10.11, 192.168.0.0/16 } oifname wan masquerade comment "output nat"
        }
}

/etc/network/interfaces

# This file describes the network interfaces available on your system
# and how to activate them. For more information, see interfaces(5).

source /etc/network/interfaces.d/*

# The loopback network interface
auto lo
iface lo inet loopback

# The primary network interface
# This is an autoconfigured IPv6 interface
allow-hotplug wan
iface wan inet static
        address 10.0.10.1
        netmask 255.255.255.0
	gateway 10.0.10.254

allow-hotplug lan
iface lan inet static
        address 192.168.1.254
        netmask 255.255.255.0
        up /usr/local/sbin/ipconf.sh

Network script

/usr/local/sbin/ipconf.sh :

#!/bin/sh

##NETWORK INTERFACES
ip link add link lan name users type vlan id 2
ip link add link lan name voip type vlan id 3
ip link add link lan name wifi type vlan id 4
ip link add link lan name servers type vlan id 5
ip link set users up
ip link set voip up
ip link set wifi up
ip link set servers up
ip addr add 192.168.2.254/24 dev users
ip addr add 192.168.3.254/24 dev voip
ip addr add 192.168.4.254/22 dev wifi
ip addr add 192.168.5.254/24 dev servers

##ROUTES
#BRANCH OFFICE 1
ip route add 192.168.12.0/24 via 192.168.1.254 src 192.168.1.254
ip route add 192.168.13.0/24 via 192.168.1.254 src 192.168.1.254
#BRANCH OFFICE 2
ip route add 192.168.22.0/24 via 192.168.1.254 src 192.168.1.254
ip route add 192.168.23.0/24 via 192.168.1.254 src 192.168.1.254

#ENABLE ROUTING
sysctl net.ipv4.ip_forward=1
echo "1" > /proc/sys/net/netfilter/nf_conntrack_acct

#RESTART SERVICES
systemctl restart racoon
setkey -f /etc/ipsec-tools.conf
systemctl restart nftables

root@host:~# chmod +x /usr/local/sbin/ipconf.sh

/etc/racoon/racoon.conf

log debug;
path pre_shared_key "/etc/racoon/psk.txt";

# phase 1 / BRANCH OFFICE 1
remote 10.0.10.11 {
        exchange_mode main,aggressive;
        my_identifier address 10.0.10.1;
        proposal_check obey;
        proposal {
                authentication_method pre_shared_key;
                encryption_algorithm aes128;
                hash_algorithm sha1;
                dh_group 1;
        }
        generate_policy off;
}

# phase 1 / BRANCH OFFICE 2
remote 10.0.10.12 {
        exchange_mode main;
        my_identifier address 10.0.10.1;
        proposal_check obey;
        proposal {
                authentication_method pre_shared_key;
                encryption_algorithm aes128;
                hash_algorithm sha1;
                dh_group 1;
        }
        generate_policy off;
}
# phase 2
sainfo anonymous {
        pfs_group 1;
        lifetime time 12 hour ;
        encryption_algorithm aes128;
        authentication_algorithm hmac_sha1;
        compression_algorithm deflate ;
}

/etc/racoon/psk.txt

10.0.10.11   password_PSK4231
10.0.10.12   password_PSK4231

/etc/ipsec-tools.conf

#!/usr/sbin/setkey -f

flush;
spdflush;

##HEADQUARTERS <-> BRANCH OFFICE 1
#lan to lan
spdadd 192.168.1.0/24 192.168.11.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;
spdadd 192.168.11.0/24 192.168.1.0/24 any -P in ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
#VoIP
spdadd 192.168.3.0/24 192.168.13.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;
spdadd 192.168.13.0/24 192.168.3.0/24 any -P in ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
#Users and Servers
spdadd 192.168.5.0/24 192.168.12.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;
spdadd 192.168.12.0/24 192.168.5.0/24 any -P in ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;

##BRANCH OFFICE 2 <-> BRANCH OFFICE 1
#BRANCH OFFICE 1 (10.0.10.11) <-> HEADQUARTERS (10.0.10.1)
spdadd 192.168.23.0/24 192.168.13.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;
spdadd 192.168.13.0/24 192.168.23.0/24 any -P in ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
#BRANCH OFFICE 2 (10.0.10.12) <-> HEADQUARTERS (10.0.10.1)
spdadd 192.168.13.0/24 192.168.23.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.12/unique;
spdadd 192.168.23.0/24 192.168.13.0/24 any -P in ipsec
        esp/tunnel/10.0.10.12-10.0.10.1/unique;

##HEADQUARTERS <-> BRANCH OFFICE 2
#lan to lan
spdadd 192.168.1.0/24 192.168.21.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.12/unique;
spdadd 192.168.21.0/24 192.168.1.0/24 any -P in ipsec
        esp/tunnel/10.0.10.12-10.0.10.1/unique;
#VoIP
spdadd 192.168.3.0/24 192.168.23.0/24 any -P out ipsec
        esp/tunnel/10.0.10.1-10.0.10.12/unique;
spdadd 192.168.23.0/24 192.168.3.0/24 any -P in ipsec
        esp/tunnel/10.0.10.12-10.0.10.1/unique;

root@host:~# systemctl restart racoon

Site 2 - Branch Office 1

Configuration

OS : Debian 8
VPN : ipsec-tools
Netfilter tool : iptables

Installation

root@host:~# apt install ipsec-tools racoon

/etc/network/interfaces

# This file describes the network interfaces available on your system
# and how to activate them. For more information, see interfaces(5).

source /etc/network/interfaces.d/*

# The loopback network interface
auto lo
iface lo inet loopback

# The primary network interface
# This is an autoconfigured IPv6 interface

auto wan
iface wan inet static
	address 10.0.10.11
        netmask 255.255.255.0
        up /usr/local/sbin/ipconf.sh

allow-hotplug lan
iface lan inet static
        address 192.168.11.254
        netmask 255.255.255.0

Network script

/usr/local/sbin/ipconf.sh :

#!/bin/sh

##REINIT IPTABLES RULES
iptables -F
iptables -X
iptables -t nat -F
iptables -t nat -X
iptables -t mangle -F
iptables -t mangle -X
iptables -P INPUT ACCEPT
iptables -P FORWARD ACCEPT
iptables -P OUTPUT ACCEPT

modprobe nf_conntrack_ftp
modprobe nf_nat_ftp

##NETWORK INTERFACES
modprobe 8021q
ip link add link lan name users type vlan id 2
ip link add link lan name voip type vlan id 3
ip link add link lan name wifi type vlan id 4
ip link set users up
ip link set voip up
ip link set wifi up
ip addr add 192.168.12.254/24 dev users
ip addr add 192.168.13.254/24 dev voip
ip addr add 192.168.14.254/24 dev wifi
echo 1 >/proc/sys/net/ipv4/ip_forward

##ROUTES
#HEADQUARTERS
ip route add 192.168.1.0/24 via 192.168.11.254 src 192.168.11.254
ip route add 192.168.3.0/24 via 192.168.13.254 src 192.168.13.254
ip route add 192.168.5.0/24 via 192.168.12.254 src 192.168.12.254
#BRANCH OFFICE 2
ip route add 192.168.23.0/24 via 192.168.13.254 src 192.168.13.254

##IPTABLES
#NOT NEEDED AS WE ACCEPT ANY BUT GOOD TO KNOW
iptables -A INPUT -s 10.0.10.1 -j ACCEPT
iptables -A INPUT -p esp -j ACCEPT
iptables -A INPUT -p udp --dport 500 -j ACCEPT
iptables -A OUTPUT -p esp -j ACCEPT
iptables -A OUTPUT -p udp --sport 500 -j ACCEPT

#AVOID IPsec trafic to be translated inside nat
iptables -t nat -A POSTROUTING -d 192.168.1.0/24 -m policy --dir out --pol ipsec -j ACCEPT
iptables -t nat -A POSTROUTING -d 192.168.3.0/24 -m policy --dir out --pol ipsec -j ACCEPT
iptables -t nat -A POSTROUTING -d 192.168.5.0/24 -m policy --dir out --pol ipsec -j ACCEPT
iptables -t nat -A POSTROUTING -d 192.168.23.0/24 -m policy --dir out --pol ipsec -j ACCEPT

/etc/racoon/racoon.conf

log debug;
path pre_shared_key "/etc/racoon/psk.txt";

# phase 1 / HEADQUARTERS
remote 10.0.10.1 {
        exchange_mode main,aggressive;
        my_identifier address 10.0.10.11;
        proposal_check obey;
        proposal {
                authentication_method pre_shared_key;
                encryption_algorithm aes128;
                hash_algorithm sha1;
                dh_group 1;
        }
        generate_policy off;
}

# phase 2
sainfo anonymous {
        pfs_group 1;
        lifetime time 12 hour ;
        encryption_algorithm aes128;
        authentication_algorithm hmac_sha1;
        compression_algorithm deflate ;
}

/etc/racoon/psk.txt

10.0.10.1   password_PSK4231

/etc/ipsec-tools.conf

#!/usr/sbin/setkey -f
flush;
spdflush;

##BRANCH OFFICE 1 <-> HEADQUARTERS
#VoIP
spdadd 192.168.13.0/24 192.168.3.0/24 any -P out ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
spdadd 192.168.3.0/24 192.168.13.0/24 any -P in ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;
#Users and Servers
spdadd 192.168.12.0/24 192.168.5.0/24 any -P out ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
spdadd 192.168.5.0/24 192.168.12.0/24 any -P in ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;

##BRANCH OFFICE 1 <-> BRANCH OFFICE 2
#VoIP
spdadd 192.168.13.0/24 192.168.23.0/24 any -P out ipsec
        esp/tunnel/10.0.10.11-10.0.10.1/unique;
spdadd 192.168.23.0/24 192.168.13.0/24 any -P in ipsec
        esp/tunnel/10.0.10.1-10.0.10.11/unique;

root@host:~# /etc/init.d/racoon restart

Site 3 - Branch Office 2

Configuration

OS : Debian 10
VPN : strongSwan
Netfilter tool : nftables

Installation

root@host:~# apt install strongswan nftables

root@host:~# systemctl enable nftables.service

/etc/nftables.conf

#!/usr/sbin/nft -f

flush ruleset

table inet filter {
        chain input {
                type filter hook input priority 0; policy accept;
	}
        chain forward {
                type filter hook forward priority 0; policy accept ;
	}
	chain output {
                type filter hook output priority 0; policy accept;
        }
}

table ip my_nat {
        chain my_masquerade {
                type nat hook postrouting priority 100;
                ip daddr != { 10.0.10.11, 192.168.0.0/16 } oifname wan masquerade comment "output nat"
        }
}

/etc/network/interfaces

# This file describes the network interfaces available on your system
# and how to activate them. For more information, see interfaces(5).

source /etc/network/interfaces.d/*

# The loopback network interface
auto lo
iface lo inet loopback

# The primary network interface
allow-hotplug wan
iface wan inet static
        address 10.0.10.12
        netmask 255.255.255.0

allow-hotplug lan
iface lan inet static
        address 192.168.21.254
        netmask 255.255.255.0
        up /usr/local/sbin/ipconf.sh

Network script

/usr/local/sbin/ipconf.sh :

#!/bin/sh

ip link add link lan name users type vlan id 2
ip link add link lan name voip type vlan id 3
ip link add link lan name wifi type vlan id 4
ip link set users up
ip link set voip up
ip link set wifi up
ip addr add 192.168.22.254/24 dev users
ip addr add 192.168.23.254/22 dev voip
ip addr add 192.168.24.254/24 dev wifi

sysctl net.ipv4.ip_forward=1

systemctl restart ipsec
systemctl restart nftables

root@host:~# chmod +x /usr/local/sbin/ipconf.sh

/etc/ipsec.conf

# ipsec.conf - strongSwan IPsec configuration file

# basic configuration

conn office2
        #charondebug = 2
        authby = secret
        auto = route
        #auto=start #https://www.questioncomputer.com/ipsec-on-linux-strongswan-configuration-ikev2-policy-based-psk/
        type = tunnel
        keyexchange = ikev1
        ike = aes128-sha1-modp768
        esp = aes128-sha1-modp768

        #BRANCH OFFICE 2
        leftfirewall = yes
        left = 10.0.10.12
        leftid = 10.0.10.12
        leftsubnet = 192.168.21.0/24

        #HEADQUARTERS
        rightfirewall = yes
        rightid = 10.0.10.1
        right = 10.0.10.1
        rightsubnet = 192.168.1.0/24

conn net-users
        also=office2
        leftsubnet = 192.168.22.0/24

conn net-voip
        also=office2
        leftsubnet = 192.168.23.0/24
        rightsubnet = 192.168.3.0/24
conn net-voip2
        also=office2
        leftsubnet = 192.168.23.0/24
        rightsubnet = 192.168.13.0/24

/etc/ipsec.secrets

: PSK password_PSK4231

root@host:~# systemctl restart ipsec.service

Comment faire des tests

Depuis Headquarters :

root@host:~# ping 192.168.21.254 -I 192.168.1.254

Depuis Branch Office 1 :

root@host:~# ping 192.168.5.254 -I 192.168.12.254

Depuis Branch Office 2 :

root@host:~# ping 192.168.13.254 -I 192.168.23.254

Vérifier les logs :

root@host:~# tail -f /var/log/syslog | grep "racoon\|charon"

Informatique

Zik

Autres

GNU/Linux - Comment mettre en place un VPN IPsec multisite entre Racoon et strongSwan

Architecture Cible

Site 1 - Headquarters

Configuration

Installation

/etc/nftables.conf

/etc/network/interfaces

Network script

/etc/racoon/racoon.conf

/etc/racoon/psk.txt

/etc/ipsec-tools.conf

Site 2 - Branch Office 1

Configuration

Installation

/etc/network/interfaces

Network script

/etc/racoon/racoon.conf

/etc/racoon/psk.txt

/etc/ipsec-tools.conf

Site 3 - Branch Office 2

Configuration

Installation

/etc/nftables.conf

/etc/network/interfaces

Network script

/etc/ipsec.conf

/etc/ipsec.secrets

Comment faire des tests
